Basic Parameters
- Load capacity: 50kg
- Travel: Standard travel options include 1800 and 2500
- Speed: 0.01-0.6m/s
- Acceleration: 0.1-1.5m/s^2
- Precision: Repeated positioning accuracy of ±0.1mm
- Position detection: Uses an absolute value encoder
- Communication method: CanOpen/EtherCat communication protocol
- Drive parameters: 1kW
- Footprint: 460x750mm, height is related to travel
- Versions: Different motor versions available such as Huichuan, LTI, and explosion-proof versions. Also, an independent version with a separate controller is available.
Features
- Heavy load: Load capacity of up to 50kg, can be mounted with multiple spray guns, and can also expand to mount a U-axis.
- Large stroke: Strokes of 1800mm and 2500mm, automatically adjusted according to the workpiece needs.
- Transmission principle and mounting portability: Adopts synchronous belt transmission, with high transmission positioning accuracy and low noise; mounted on both sides, with easy mounting and high expand-ability.
